| Database |
NEUBREGATE |
| Optical switch |
1x8ch (Prime100), 2x8ch or 1x16ch (Prime200), up to 2x32ch |
| Fiber connector |
FC-APC(Default) / SC-APC(Optional) |
| Input-output fIber |
Single mode optical fiber |
| CPU |
Intel or AMD High performnace CPU |
| RAM |
64GB |
| Storage |
SSD 1TB and HDD 8TB RAID1 |
| OS |
Windows11 Pro (64 bit) |
| Power unit |
AC 100~240V, 50/60 Hz, 250 VA |
| Dimensions / Weight |
448(W) × 657(D) ×297(H) mm / Approx. 15 kg |
| Operating temperature |
10~40℃, Humidity below 85% (no dew condensation) |
| Storage temperature |
0~50℃ |
| I/O interface |
HDMI x1, USB3.0 x4, RJ45(Gigabit LAN) x1 |
| Place of production |
Japan |
